SWIVEL MALE RUN TEE BSPT(R) THREAD R3/8 , TUBE SIZE OD8, BLACK - HRST08R03B

Product Type: Rotatable T-connector with base
Tube Connection Dimensions: Ø8 mm
Base Thread: BSPT (R/RP) R3/8 (male)
Connection Mechanism: Push-to-connect for tubing, threaded for the base
Color: Black
Material: High-quality plastic
Operating Pressure: Up to 150 PSI
Temperature Range: 0°C to +65°C
Applications: Pneumatic systems, water treatment systems, industrial setups.

Code: 01.00080

Availability: Available

Minimum quantity: 2 items

3.56€

/ Item

Wishlist

Compare products

Description

The HRST08R03B rotatable T-connector with base is designed for tubing connections requiring three-point connectivity. The side ports support Ø8 mm tubing with push-to-connect mechanisms, while the base features a BSPT (R/RP) R3/8 male thread for secure mounting.
The rotatable design allows for flexible installation and adjustment in confined spaces. Made from durable high-quality plastic and finished in black, this connector operates under pressures up to 150 PSI and temperatures ranging from 0°C to +65°C, making it suitable for pneumatic systems, water treatment setups, and industrial applications.

Features

Temperature:: 0/65 °C

Max Pressure:: 150 psi (10,3 bar)

Connection Type:: Push-to-connect για τον σωλήνα, σπείρωμα για τη βάση

Material:: High-quality plastic

Inlet:: 8 mm

Outlet:: R 3/8"
