SWIVEL MALE ELBOW BSPT(R) THREAD 1/8 NPT, TUBE SIZE 5/16 - HRPL5/16-N01G

Product Type: Rotatable elbow base connector
Tube Connection Dimensions: 5/16" (Ø7.94 mm)
Thread: BSPT (R/RP) 1/8 NPT (male)
Connection Mechanism: Push-to-connect for tubing, threaded for the base
Material: High-quality plastic
Operating Pressure: Up to 150 PSI
Temperature Range: 0°C to +65°C
Applications: Water treatment systems, pneumatic systems, industrial setups.

Code: 01.00073

Availability: Available

Minimum quantity: 2 items

3.07€

/ Item

Wishlist

Compare products

Description

The HRPL5/16-N01G rotatable elbow base connector is designed for flexible tubing connections, offering rotation for easy adjustment and installation.
The push-to-connect inlet supports secure and quick connections for 5/16" tubing, while the BSPT (R/RP) 1/8 NPT male thread ensures a stable and leak-proof connection to the base.
Made from high-quality plastic, this connector operates under pressures up to 150 PSI and temperatures ranging from 0°C to +65°C, making it ideal for pneumatic systems, water treatment setups, and industrial applications.
