FW6273 HO UV DISINFECTION SYSTEM

  • Maximum flow rate: 133 m³/h (at 30 mJ/cm²), 100 m³/h (at 40 mJ/cm²)
  • UV lamps: 6 x 87 W
  • Inlet/Outlet diameter: 4"
  • Reactor length: 1162 mm
  • Stainless-steel reactor
  • Integrated UV sensor with LED alarm and dry contacts
  • Suitable for freshwater UVT 70-98%
  • Operating temperature up to 35°C
  • Easy vertical or horizontal installation
  • Low energy consumption
Code: 09.00013
Availability: Pre-order
9626.06€
/ Item

Share

Description

The BIO-UV FW6273 HO UV water disinfection system is specifically designed to deliver powerful and reliable UV treatment for high-quality freshwater applications with UV transmittance ranging from 70% to 98%. Built with a robust stainless-steel reactor and six low-pressure, high-output UV lamps (6 x 87 W), it ensures exceptional disinfection capability even under cold or temperate conditions up to 35°C. The integrated UV sensor provides continuous operation monitoring with an LED alarm system and dry contacts for simplified process management. Its compact, versatile construction allows easy vertical or horizontal installation, minimal maintenance requirements, and significant operational energy savings. Ideally suited for large municipal, commercial, and industrial installations, the stainless-steel reactor comes with a 5-year warranty.
