Filtration & Water Softening

Filtration Degree: 0,5 μm
Capacity: 53.500 Lt
Flow rate: 400 Lt/h
Temperature range: 6 / 38° C
Μax pressure: 8 bar
Μaximum Duration: 1 year after installation

Filtration Degree: 0,5μm
Capacity: 12.000 Lt
Flow rate: 300 Lt/h
Temperature range: 6/38° C
Μax pressure: 6 bar
Μaximum Duration: 1 year after installation

Connection Type: Thread

Measure: 3/8"

Single filter head with by-pass function, compatible with all Fil.Tech filters.

Filtration Degree: 0,5μm
Capacity: 23.000 Lt
Flow rate: 400 Lt/h
Temperature range: 6 / 38° C
Μax pressure: 8 bar
Μaximum Duration: 1 year after installation

Connection Type: Thread

Measure: 3/8"

Single filter head compatible with all Fil.Tech filters.

Filtration Degree: 0,1μm
Capacity: 35.000 Lt
Flow rate: 300 Lt/h
Temperature range: 6 / 38° C
Μax pressure: 6 bar
Μaximum Duration: 1 year after installation

Filtration Degree: 0,5μm
Capacity: 35.000 Lt
Flow rate: 300 Lt/h
Temperature range: 6 / 38° C
Μax pressure: 6 bar
Μaximum Duration: 1 year after installation

Filtration Degree: 0,5μm
Capacity: 45000 l
Flow rate: 400 I /h
Temperature range: 6 / 38° C
Μax pressure: 8 bar
Μaximum Duration: 1 year after installation

It can be combined with filter head 03.00018

Filtration Degree: 5μm
Capacity: 500000 Lt
Flow rate: 1000 Lt /h
Temperature range: 6 / 38° C
Μax pressure: 8 bar
Μaximum Duration: 1 year after installation

It can be combined with filter head 03.00018

Filtration Degree: 5μm
Capacity: 12000 l
Flow rate: 300 I /h
Temperature range: 5 / 38° C
Μax pressure: 6 bar
Μaximum Duration: 1 year after installation

• Filter Length: 20 inches (508 mm).
• Connection Diameter: 3/4" BSP.
• Material:
  • Head made of reinforced polypropylene (blue color).
  • Bowl made of transparent PET.
• Sealing: O-ring made of NBR.
• Maximum Operating Pressure: 8.6 bar.
• Operating Temperature Range: 4°C to 40°C.
• Additional Equipment: Air valve for decompression.

• Filter Length: 10 inches (254 mm).
• Material Construction:
  • Head: Reinforced nylon (grey color).
  • Bowl: Transparent PET or grey polypropylene.
• IN/OUT Connection: 3/4" BSP.
• Compatibility: Suitable for standard DOE cartridges with a length of 10".
• Maximum Operating Pressure: 8.6 bar.
• Temperature Range: 4°C to 80°C.
• Sealing: O-ring made of EPDM.
• Additional Equipment: Includes a pressure relief valve.

• Filter Length: 5 inches (126 mm).
• Diameter:
  • Outer: 64 mm.
  • Inner: 25 mm.
• Filtration Rating: 5 Micron.
• Material: Melt-blown polypropylene.
• Maximum Operating Temperature: 45°C.

• Filter Length: 10 inches (252 mm).
• Outer Diameter: 70 mm.
• Material: High-strength plastic.
• Capacity: 0.6 liters.
• Compatibility: Suitable for filling with polyphosphate crystals, activated carbon, or resins.
• Operating Temperature: Up to 40°C.

• Filter Length: 10 inches (252 mm).
• Outer Diameter: 70 mm.
• Material: High-strength plastic.
• Capacity: 0.6 liters.
• Compatibility: Suitable for filling with polyphosphate crystals, activated carbon, or resins.
• Operating Temperature: Up to 40°C.

• Filter Length: 20 inches.
• Diameter:
  • Outer: 62 mm.
  • Inner: 27 mm.
• Filtration Rating: 50 Micron.
• Material: Washable polyester mesh.

• Filter Length: 10 inches (248 mm).
• Diameter:
  • Outer: 62 mm.
  • Inner: 27 mm.
• Filtration Rating: 50 Micron.
• Material: Polyester.
• Operating Temperature: Maximum 38°C.
• Maximum Pressure Drop (∆P): 4 bar.

• Filter Length: 20 inches (508 mm).
• Diameter:
  • Outer: 65 mm.
  • Inner: 28 mm.
  • End Cap Diameter: 65 mm.
• Filtration Rating: 10 Micron.
• Material: Extruded activated carbon of Bituminous origin.
• Nominal Filtration Flow Rate: 480 l/h.
• Maximum Operating Temperature: 50°C.
• Maximum Differential Pressure (∆P): 1 bar.

• Filter Length: 10 inches (250 mm).
• Diameter:
  • Outer: 62 mm.
  • Inner: 30 mm.
  • End Cap Diameter: 65 mm.
• Filtration Rating: 10 Micron.
• Material: Extruded activated carbon of industrial-grade origin.
• Nominal Filtration Flow Rate: 240 l/h.
• Maximum Operating Temperature: 50°C.

• Filter Length: 20 inches (508 mm).
• Diameter:
  • Outer: 63 mm.
  • Inner: 28 mm.
• Filtration Rating: 20 Micron.
• Material: Melt-blown polypropylene fibers.
• Nominal Filtration Flow Rate: 40-60 lpm.
• Maximum Operating Temperature: 80°C.
• Maximum Differential Pressure (∆P): 1.4 bar.

• Filter Length: 20 inches (508 mm).
• Diameter:
  • Outer: 63 mm.
  • Inner: 28 mm.
• Filtration Rating: 10 Micron.
• Material: Melt-blown polypropylene.
• Nominal Filtration Flow Rate: 15-20 lpm.
• Maximum Operating Temperature: 80°C.
• Maximum Differential Pressure (∆P): 1.4 bar.

• Filter Length: 20 inches (508 mm).
• Diameter:
  • Outer: 63 mm.
  • Inner: 28 mm.
• Filtration Rating: 5 Micron.
• Material: Melt-blown polypropylene.
• Nominal Filtration Flow Rate: 15-20 lpm.
• Maximum Operating Temperature: 80°C.
• Maximum Differential Pressure (∆P): 1.4 bar.

• Filter Length: 20 inches (508 mm).
• Diameter:
  • Outer: 114 mm (Big Blue).
  • Inner: 28 mm.
• Filtration Rating: 20 Micron.
• Material: Melt-blown polypropylene fibers.
• Nominal Filtration Flow Rate: 15-20 lpm.
• Maximum Operating Temperature: 80°C.
• Maximum Differential Pressure (∆P): 1.4 bar.

• Filter Length: 9 7/8" (251 mm).
• Diameter:
  • Outer: 63 mm.
  • Inner: 28 mm.
• Filtration Rating: 10 Micron.
• Material: Melt-blown polypropylene fibers.
• Nominal Filtration Flow Rate: 15-20 lpm.
• Maximum Operating Temperature: 80°C.
• Maximum Differential Pressure (∆P): 1.4 bar.

• Filter Length: 9 7/8 inches (251 mm).
• Diameter:
  • Outer: 63 mm.
  • Inner: 28 mm.
• Filtration Rating: 1 Micron.
• Material: Melt-blown polypropylene fibers.
• Nominal Filtration Flow Rate: 15-20 lpm.
• Maximum Operating Temperature: 80°C.

• Filter Length: 20 inches (508 mm).
• Diameter:
  • Outer: 114 mm (Big Blue).
  • Inner: 28 mm.
• Filtration Rating: 20 Micron.
• Material: Melt-blown polypropylene fibers.
• Nominal Filtration Flow Rate: 90-120 lpm.
• Maximum Operating Temperature: 80°C.
• Maximum Differential Pressure (∆P): 1.4 bar.

• Filter Length: 20 inches (508 mm).
• Diameter:
  • Outer: 114 mm (Big Blue).
  • Inner: 28 mm.
• Filtration Rating: 1 Micron.
• Material: Melt-blown polypropylene fibers.
• Nominal Filtration Flow Rate: 90-120 lpm.
• Maximum Operating Temperature: 65°C.
• Maximum Differential Pressure (∆P): 1.4 bar.

• Filter Length: 20 inches (508 mm).
• Diameter:
  • Outer: 114 mm (Big Blue).
  • Inner: 28 mm.
• Filtration Rating: 5 Micron.
• Material: Melt-blown polypropylene fibers.
• Nominal Filtration Flow Rate: 120 lpm.
• Maximum Operating Temperature: 65°C.
• Maximum Differential Pressure (∆P): 1.4 bar.

• Filter Length: 10 inches (251 mm).
• Diameter:
  • Outer: 114 mm.
  • Inner: 28 mm.
• Filtration Rating: 20 Micron.
• Material: Melt-blown polypropylene fibers (PP).
• Maximum Operating Temperature: 65°C.
