MPN: 10.00022
DANFOSS COUPLING AND BELL HOUSING FOR APP 5,1 - 10,2 - MOTOR SIZE IEC 100 - 180Z0217
- Compatibility: Suitable for high-pressure Danfoss APP 5.1-10.2 and PAH 50-100 pumps
- Motor shaft diameter: 42 mm
- Pump shaft diameter: 32 mm
- Set Includes:
- Bell housing for IEC 160 motor frame
- Elastic coupling for vibration absorption and proper alignment between pump and motor
- Construction Materials: High-strength aluminum and elastomers designed for durability in high-pressure applications
- Installation: Designed for easy assembly and reliable, long-lasting operation
596.66€
MPN: 10.00021
DANFOSS COUPLING AND BELL HOUSING FOR APP 0,6 - 3,5 - MOTOR SIZE IEC 132 - 180Z0215
- Compatibility: Suitable for high-pressure Danfoss APP pumps from 0.6 to 3.5
- Motor shaft diameter: 38 mm
- Pump shaft diameter: 24 mm
- Set Includes:
- Bell housing for IEC 132 motor frame
- Elastic coupling for vibration absorption and proper alignment between pump and motor
- Construction Materials: High-strength metals and elastomers designed for durability in high-pressure applications
- Installation: Engineered for easy assembly and reliable, long-lasting operation
468.27€
MPN: 10.00020
HIGH PRESSURE PUMP DANFOSS APP 10.2 - 180B3010
- Geometric Displacement: 100.5 cm³/rev
- Maximum Outlet Pressure: 83 barg (1200 psig)
- Minimum Outlet Pressure: 20 barg (290 psig)
- Inlet Pressure: 0.5 - 5 barg (7.3 - 72.5 psig)
- Maximum Flow (at 1800 RPM): 45.71 gpm (10.4 m³/h)
- Media Temperature: 2 - 50°C (35.6 - 122°F)
- Ambient Temperature: 0 - 50°C (32 - 122°F)
- Sound Pressure Level: 78 dB(A)
MPN: 10.00019
HIGH PRESSURE PUMP DANFOSS APP 8.2 - 180B3008
- Geometric Displacement: 80.4 cm³/rev
- Maximum Outlet Pressure: 83 barg (1200 psig)
- Minimum Outlet Pressure: 20 barg (290 psig)
- Inlet Pressure: 0.5 - 5 barg (7.3 - 72.5 psig)
- Maximum Flow (at 1800 RPM): 36.59 gpm (8.32 m³/h)
- Media Temperature: 2 - 50°C (35.6 - 122°F)
- Ambient Temperature: 0 - 50°C (32 - 122°F)
- Sound Pressure Level: 78 dB(A)
11077.23€
MPN: 10.00018
HIGH PRESSURE PUMP DANFOSS APP 7.2 - 180B3007
- Geometric Displacement: 70.3 cm³/rev
- Maximum Outlet Pressure: 83 barg (1200 psig)
- Minimum Outlet Pressure: 20 barg (290 psig)
- Inlet Pressure: 0.5 - 5 barg (7.3 - 72.5 psig)
- Maximum Flow (at 1800 RPM): 31.74 gpm (7.22 m³/h)
- Media Temperature: 2 - 50°C (35.6 - 122°F)
- Ambient Temperature: 0 - 50°C (32 - 122°F)
- Sound Pressure Level: 78 dB(A)
MPN: 10.00017
HIGH PRESSURE PUMP DANFOSS APP 6.5 - 180B3006
- Geometric Displacement: 63.3 cm³/rev
- Maximum Outlet Pressure: 83 barg (1200 psig)
- Minimum Outlet Pressure: 20 barg (290 psig)
- Inlet Pressure: 0.5 - 5 barg (7.3 - 72.5 psig)
- Maximum Flow (at 1800 RPM): 28.31 gpm (6.5 m³/h)
- Media Temperature: 2 - 50°C (35.6 - 122°F)
- Ambient Temperature: 0 - 50°C (32 - 122°F)
- Sound Pressure Level: 78 dB(A)
MPN: 10.00016
HIGH PRESSURE PUMP DANFOSS APP 5.1 - 180B3005
- Geometric Displacement: 50.2 cm³/rev
- Maximum Outlet Pressure: 83 barg (1200 psig)
- Minimum Outlet Pressure: 20 barg (290 psig)
- Inlet Pressure: 0.5 - 5 barg (7.3 - 72.5 psig)
- Maximum Flow (at 1800 RPM): 22.13 gpm (5.02 m³/h)
- Media Temperature: 2 - 50°C (35.6 - 122°F)
- Ambient Temperature: 0 - 50°C (32 - 122°F)
- Sound Pressure Level: 78 dB(A)
MPN: 10.00015
DANFOSS VALVE PLATE SET APP 1.5-2.5 - 180B4145
- Compatibility: Suitable for APP 1.5, APP 1.8, APP 2.2, and APP 2.5 pumps.
- Material Construction: High-quality materials resistant to corrosion and high pressures.
- Contents: Includes valve plates and related components for pump performance restoration.
- Installation: Easy installation following the manufacturer’s instructions.
1134.69€
MPN: 10.00014
DANFOSS PISTON SET FOR APP 1,5 - 2,5 - 180B4143
- Compatibility: Suitable for APP 1.5, APP 1.8, APP 2.2, and APP 2.5 pumps.
- Material Construction: Made from high-quality corrosion-resistant materials for high-pressure applications.
- Contents: Includes pistons and related components necessary to maintain pump performance.
- Installation: Requires specialized tools and adherence to the manufacturer's instructions.
1985.71€
MPN: 10.00013
DANFOSS SEAL SET APP FOR 1,5 - 2,5 - 180B4147
- Compatibility: Suitable for APP 1.5, APP 1.8, APP 2.2, and APP 2.5 pumps.
- Materials: High-quality materials resistant to corrosion and high pressure.
- Installation: Designed for easy installation and maintenance as per the manufacturer’s specifications.
387.69€
MPN: 10.00012
DANFOSS COUPLING FOR APP 0,6 - 3,5 - MOTOR SIZE IEC 132 - 180Z0244
- Compatibility: Suitable for APP 0.6, APP 0.8, APP 1.0, APP 1.5, APP 2.2, and APP 3.5 pumps.
- Motor shaft diameter: 38 mm
- Pump shaft diameter: 16 mm
- Material Construction: High-quality, durable materials designed for high-pressure conditions.
- Usage: Designed for connecting pumps with IEC 132 motors.
- Advantages: Vibration absorption, easy alignment, and reduced wear.
192.23€
MPN: 10.00011
DANFOSS COUPLING FOR APP 0,6 - 3,5 - MOTOR SIZE IEC 100/112 - 180Z0243
- Compatibility: Suitable for APP 0.6, APP 0.8, APP 1.0, APP 1.5, APP 2.2, and APP 3.5 pumps.
- Motor shaft diameter: 28 mm
- Pump shaft diameter: 16 mm
- Material Construction: High-quality, durable materials designed for high-pressure applications.
- Usage: Ensures reliable and precise connection of pumps with IEC 100/112 motors.
- Advantages: Vibration absorption, precise alignment, and reduced wear.
149.23€
MPN: 10.00010
DANFOSS COUPLING AND BELL HOUSING FOR APP 5,1 - 10,2 - MOTOR SIZE IEC 100 - 180Z0216
- Compatibility: Suitable for high-pressure pumps APP 5.1, APP 6.5, APP 7.2, APP 8.2, and APP 10.2.
- Motor shaft diameter: 38 mm
- Pump shaft diameter: 32 mm
- Kit Contents:
- Bell housing for IEC 100 motor.
- Elastic coupling for vibration absorption and proper alignment of pump and motor.
- Material Construction: High-strength materials designed for durability under high-pressure conditions.
- Installation: Easy assembly for reliable and long-lasting operation.
508.03€
MPN: 10.00009
DANFOSS COUPLING AND BELL HOUSING FOR APP 0,6 - 3,5 - MOTOR SIZE IEC 100 - 180Z0045
- Compatibility: Suitable for APP 0.6, APP 0.8, APP 1.0, APP 1.5, APP 2.2, and APP 3.5 pumps.
- Motor shaft diameter: 28 mm
- Pump shaft diameter:16 mm
- Kit Contents:
-
- Bell housing for IEC 100 motor.
- Elastic coupling for vibration damping and precise alignment.
- Material Construction: Made from durable materials designed for long-term use under high-pressure conditions.
- Installation: Easy assembly for pump and motor alignment, ensuring optimal performance.
344.00€
MPN: 10.00008
HIGH PRESSURE PUMP DANFOSS APP 2.5 - 180B3046
- Geometric Displacement: 15.35 cm³/rev (0.94 in³/rev).
- Maximum Outlet Pressure (Continuous): 83 barg (1200 psig).
- Minimum Outlet Pressure: 20 barg (290 psig).
- Inlet Pressure (Continuous): 0.5 - 5 barg (7.3 - 72.5 psig).
- Maximum Flow:
- At 1000 rpm: 0.90 m³/h.
- At 1500 rpm: 1.34 m³/h.
- Media Temperature: 2°C - 50°C (36°F - 122°F).
- Ambient Temperature: 0°C - 50°C (32°F - 122°F).
- Sound Pressure Level: 81 dB(A).
8741.64€
MPN: 10.00007
HIGH PRESSURE PUMP DANFOSS APP 2.2 - 180B3045
- Geometric Displacement: 12.52 cm³/rev (0.76 in³/rev).
- Maximum Outlet Pressure (Continuous): 83 barg (1200 psig).
- Minimum Outlet Pressure: 20 barg (290 psig).
- Inlet Pressure (Continuous): 0.5 - 5 barg (7.3 - 72.5 psig).
- Maximum Flow:
- At 1000 rpm: 0.73 m³/h.
- At 1500 rpm: 1.09 m³/h.
- Media Temperature: 2°C - 50°C (36°F - 122°F).
- Ambient Temperature: 0°C - 50°C (32°F - 122°F).
- Sound Pressure Level: 77 dB(A).
7454.21€
MPN: 10.00006
HIGH PRESSURE PUMP DANFOSS APP 3.5 - 180B3032
- Geometric Displacement: 20.54 cm³/rev (1.25 in³/rev).
- Maximum Outlet Pressure (Continuous): 83 barg (1200 psig).
- Minimum Outlet Pressure: 20 barg (290 psig).
- Inlet Pressure (Continuous): 0.5 - 5 barg (7.3 - 72.5 psig).
- Maximum Flow:
- At 1000 rpm: 1.19 m³/h.
- At 1500 rpm: 1.79 m³/h.
- Media Temperature: 2°C - 50°C (36°F - 122°F).
- Ambient Temperature: 0°C - 50°C (32°F - 122°F).
- Sound Pressure Level: 81 dB(A).
12215.17€
MPN: 10.00005
DANFOSS RETAINER SET APP 5.1-8.2 - 180B4156
- Compatibility: Suitable for high-pressure pumps APP 5.1, APP 6.5, APP 7.2, and APP 8.2.
- Materials: High-quality materials such as Duplex and Super Duplex stainless steel, resistant to corrosion.
- Contents: Includes all necessary retaining components to ensure stability and reliability of the pumps.
- Installation: Designed for easy installation and maintenance according to the manufacturer’s specifications.
1419.00€
MPN: 10.00003
DANFOSS SEAL SET APP 5.1-10.2 - 180B4161
- Compatibility: Suitable for high-pressure pumps APP 5.1, APP 6.5, APP 7.2, APP 8.2, and APP 10.2.
- Materials: High-quality materials such as Duplex and Super Duplex stainless steel, resistant to corrosion.
- Contents: Includes all necessary sealing components for pump maintenance and sealing restoration.
- Installation: Easy installation following the manufacturer’s specifications.
1378.53€
MPN: 10.00002
DANFOSS VALVE PLATE KIT APP 5.1-8.2 - 180B4158
- Compatibility: Suitable for APP 5.1, APP 6.5, APP 7.2, and APP 8.2 pumps.
- Material: Made of Super Duplex steel for corrosion resistance and long-lasting performance.
- Kit Contents: Valve plates and components for easy maintenance and replacement.
- Maintenance: Designed for replacement after 24,000 operating hours, as per Danfoss specifications.
2413.07€
MPN: 10.00001
DANFOSS PISTON SET APP 5.1-8.2 - 180B4154
- Applications: Designed for replacement and maintenance of high-pressure pumps APP 5.1-8.2.
- Materials: Made from high-strength materials such as Duplex and Super Duplex steel for corrosion resistance.
- Maintenance Requirements: Easy installation and maintenance. Recommended to be performed by qualified personnel following the manufacturer’s specifications.
- Usage: Ideal for desalination and reverse osmosis systems requiring reliability and high performance.
3515.00€
